15
List of parts
Serial no.
Qty. Name Material
17 1 Rear wingspar connector Injected plastic
18 1 Wing strut bracket fuselage Milled GRP
19 2 Wing strut bracket wing Injected plastic
20 2 Rudder horn landing aps Injected plastic
21 6 Landing ap hinges A Injected plastic
22 4 Landing ap hinges B Injected plastic
23 3 Twin rudder horn Injected plastic
24 1 Holder for spinner Injected plastic
25 2 Canopy locking clip Injected plastic
26 2 Canopy closure plug Injected plastic
27 2 Undercarriage mount Injected plastic
Plastic parts
Serial no.
Qty. Name Material
28 1 Square tube GRP
29 2 Threaded rod Galvanized steel
30 2 Tube CFRP
31 2 Fuselage belt GRP
Strut tube kit
Serial no.
Qty. Name Material
32 1 Undercarriage mount counter plate Injected plastic
33 2 Lightweight wheel Foamed ELAPOR
34 1 Super lightweight wheel Foamed ELAPOR
35 1 Main undercarriage Nickel-plated spring steel
36 1 Tailwheel wire Spring steel
37 4 Cross-head screw Galvanized steel
38 1 Tubular rivet Brass
39 5 Set screw Black-oxide steel
40 4 Set collar Nickel-plated brass
41 1 Set collar Nickel-plated brass
Undercarriage kit
Serial no.
Qty. Name Material
42 6 Set screw Black-oxide steel
43 3 Pushrod connector Aluminum
44 2 Fillister head self-tapping screw Galvanized steel
45 9 Nut Brass
46 4 Metal fork head Spring steel
47 3 Cardan bolt Aluminum
48 2 Nut Galvanized steel
49 3 Washer Brass
Set of screws
Serial no.
Qty. Name Material
50 2 Elevator / Rudder pushrod Spring steel
51 2 Aileron pushrod Spring steel
52 3 Landing aps / Aero-tow release pushrod Spring steel
Bag of accessories
