Dual Rate Setting
Aileron
Elevator
Flap
Rudder
Note: When aps are released, the aircraft will be heading up, so mixed elevator control is required for good landings. It requires 1mm height lower
for high dual-rate ap and 2mm lower for low dual-rate ap.
Aileron Elevator Rudder Flaps
Low dual rate (H1/H2) 8 mm 6 mm 10 mm 8-10 mm
High dual rate (H1/H2) 10 mm 8 mm 14 mm 18-22 mm
