Multiplex PARTENAVIA P.68 - Assembly Instructions; Main Landing Gear Installation; Horizontal Stabilizer Installation

M3x26mm
M3x10mm
18
Assembly instructions
1. Place the horizontal stabilizer into the slot of the tail as shown and x
it with supplied screws.
2. Connect the linkage rod with control horn and elevator servo arm.
Horizontal Stabilizer Installation
Fit the main landing gear into the slot of the bottom and use landing gear cover & supplied screws to secure it.
Main Landing Gear Installation
EN
