PAGE 14 — J36/B46-M30 SERIES WALK-BEHIND TROWELS • OPERATION MANUAL — REV. #1 (11/17/17)
SPECIFICATIONS (ENGINE)
Table 3. Honda Engine Specifications
Model
Honda
GX160UT2QX2
Honda
GX270UTQA2
Honda
GX340U1QAP2
Trowel JH55C/M30H55
J36H90/J36H90H
B46H90
B46H11/B46H11H
Type
Air-cooled, 4-stroke, single-cylinder, OHV, horizontal PTO shaft,
gasoline engine
Bore × Stroke
2.70 in. × 1.8 in.
(69 mm × 46 mm)
3.0 in. × 2.3 in.
(76 mm × 58 mm)
3.2 in. × 2.5 in.
(81 mm × 64 mm)
Displacement 163 cm³ 270 cm³ 387 cm³
Max Output 5.4 hp @ 3600 rpm 9 hp @ 3600 rpm 11 hp @ 3600 rpm
Fuel Tank Capacity
~ 0.95 U.S. gallons
(3.6 liters)
~ 1.59 U.S. gallons
(6.02 liters)
~ 1.72 U.S. gallons
(6.5 liters)
Fuel Unleaded gasoline
Lube Oil Capacity 0.63 qt. (0.6 liters) 1.06 qt. (1.0 liters) 1.06 qt. (1.0 liters)
Oil Type 4-stroke API, SF or SG SAE 10W-30 general use
Speed Control
Method
Centrifugal flyweight type
Starting Method Recoil start
Dimensions
(L × W × H)
12.3 × 14.3 × 13.2 in.
(312 × 363 × 335 mm
14.0 × 16.9 × 16.1 in.
(356 × 429 × 409 mm)
16.7 × 17.7 × 17.4 in.
(424 × 450 × 442 mm)
Dry Net Weight 33.1 lb. (15 kg) 55.1 lb. (25 kg) 68 lbs (29 Kg.)
Table 4. Robin/Subaru Engine Specifications
Model
Robin
EX170D50040
Robin
EX270D50020
Subaru
EX170DM2230
Subaru
EX270D5E5013
Trowel J36R60
J36R90/J36R90H
B46R90
J36S60 B46S90
Type
Air-cooled, 4-stroke, slant single cylinder, OHC,
horizontal PTO shaft, gasoline engine
Bore × Stroke
2.64 in. × 1.89 in.
(67 mm × 48 mm)
2.95 in. × 2.36 in.
(75 mm × 60 mm)
2.64 in. × 1.89 in.
(67 mm × 48 mm)
2.95 in. × 2.36 in.
(75 mm × 60 mm)
Displacement 169 cm³ 265 cm³ 10.31 in³ (169 cm³) 265 cm³
Max Output 5.7 hp @ 4000 rpm 9 hp @ 4000 rpm 5.7 hp @ 4000 rpm 9 hp @ 4000 rpm
Fuel Tank Capacity
~ 0.95 U.S. gallons
(3.6 liters)
~ 1.59 U.S. gallons
(6.02 liters)
~ 0.95 U.S. gallons
(3.6 liters)
~ 1.59 U.S. gallons
(6.02 liters)
Fuel Unleaded gasoline
Lube Oil Capacity 0.63 qt. (0.6 liters) 1.06 qt. (1.0 liters) 0.63 qt. (0.6 liters) 1.06 qt. (1.0 liters)
Oil Type 4-stroke API, SF or SG SAE 10W-30 general use
Speed Control
Method
Centrifugal flyweight type
Starting Method Recoil start
Dimensions
(L × W × H)
11.97 × 13.94 × 13.2 in.
(304 × 354 × 335 mm)
13.82 × 16.54 × 16.14 in.
(351 × 420 × 410 mm)
11.97 × 13.94 × 13.19 in.
(304 × 354 × 335 mm)
13.82 × 16.54 × 16.14 in.
(351 × 420 × 410 mm)
Dry Net Weight 33.1 lb. (15 kg) 46.3 lb. (21 kg) 33.1 lb. (15 kg) 46.3 lb. (21 kg)
