J36/B46-M30 SERIES WALK-BEHIND TROWELS • OPERATION MANUAL — REV. #1 (11/17/17) — PAGE 13
SPECIFICATIONS (TROWEL)
Table 1. J-Series Trowel Specifications
Model J36H55/J36R60/J36S60 J36H90/J36R90 J36H90H/J36R90H M30H55
Number of Blades 4
Ring Diameter 36 in. (914 mm) 30 in. (762 mm)
Rotor RPM 60–115 60–130 90–155 60–130
Path Width 34.5 in. (876 mm) 28.67 in. (728 mm)
Shipping Weight 182 lb. (82.6 kg) 182 lb. (82.6 kg) 207 lb. (93.9 kg) 195 lb. (88.5 kg)
Table 2. B-Series Trowel Specifications
Model B46H90/B46R90/B46H11 B46H11H B46S90
Number of Blades 4
Ring Diameter 46.5 in. (1,181 mm)
Rotor - RPM 60–130 90–155 60–130
Path Width 46 in. (1,168 mm)
Shipping Weight 285 lb. (129.3 kg) 300 lb. (136.1 kg)
