MULTIQUIP LS450 - Dimensions

PAGE 12 — MAYCO LS450 CONCRETE PUMP • OPERATION MANUAL — REV. #2 (02/23/21)
Figure 1. Pump Dimensions
A
C
D
B
E
DIMENSIONS
Table 3. Pump Dimensions
Reference
Letter
Dimensions
in. (mm)
A 44 (1,117)
B 173 (4,394)
C 24 (610)
D 70 (1,778)
E 68 (1,727)
