MULTISPAN MS 1248-M1 - Product Inception; Technical Specifications

UPPER: 4 Digit 7 seg 0.70”, LED DisplayRED
LOWER: 4 Digit 7 seg 0.50”, LED Display GREEN
Output
Power Supply
Operating
Temperature
Relative
Humidity
100 to 270V AC,50/60 Hz, Approx 4VA
0°C To 55°C
Up to 95% RH Non Condensing
Model
Display
Size (mm)
Panel Cutout
96 (H) X 96 (W) X 50 (D) mm
92 X 92 mm
MS 1248-M1
4 Relay (NO-C-NC) 1C/O 5A@230V AC, 5A for resistive load
with RS-485 RTU MODBUS
www.multispanindia.com
Product Inception
Technical Specifications
To go to
Parameter
Setting
Upper Display
( ) RED
Lower Display
( ) GREEN
To change the value
or select option
To save changes
in settings
Alarm Indication
every channel
4 Relay Indication
MS 1248-M1
SCANNER
SET
ENT
1CH 2 3 4 5 6 7 8
T/H
H/L
R1
R2
R3
R4
SCROLL
7Low
5 0 0
Page-1
PT-100/3W -99 to 400°C
PT.1/3W -99.0 to 400.0°C
Thermocouple
RTD
Inputs and
Range
J 0 to 600°C
K 0 to 1200°C
MS-1248-M1
SCROLL
Protection Level
IP-65 (Front side) AS per IS/IEC 60529 : 2001
