MULTISPAN PID 2303-3C - Page 6

PARAMETER SETTING
Page 6
Control Parameter
(If R2MD = BL.TP)
Press key to
save & exit
ENT
Proportional Band
PID Action
Integral Time
Derivative Time
Cycle Time
Manual Reset
Proportional Band 2
Cycle Time 2
Manual Reset 2
pass
37
Enter Password 37
OFF-SET
OFST
0
SLL
0
SHL
400
Set Point Low Limit
Set Point High Limit
r3md
ALRM
Case 4 :- If OFF Select
OFF
Relay 3 Mode
Alarm
off
Case 3 :- INB, ABO
SET3
LOW
75
SET3
HI H
125
Set Point 3
Low
Set Point 3
High
Alarm time
ALRM
TIME
5
time
SLL
SHL
OFST
0
400
0
Set Point Low Limit
Set Point High Limit
Offset
HB-1
H1
4.0
Heater 1 Break Indication
Set Point
HB-1
H2
4.0
Heater 2 Break Indication
Set Point
HB-1
H3
4.0
Heater 3 Break Indication
Set Point
HB-1
H1
4.0
Heater 1 Break Indication
Set Point
HB-1
H2
4.0
Heater 2 Break Indication
Set Point
HB-1
H3
4.0
Heater 3 Break Indication
Set Point
