SPECIFICATIONS AND RELATED INFORMATION
10 Conduit
®
Base Station IP67 for Europe and Asia MTCDTIP-L4E1 Hardware Guide
Label LED Description
L1 LoRa 1 User-defined. Can be red or green.
L2 LoRa 2
LED Programming Notes
mPower LED Notes
For mPower models
The default state of the L1 and L2 LEDs depends on the cellular connection (connected/disconnected) and
signal strength.
To change the LED behavior modify the script /sbin/led_cd_ss.
mLinux LED Notes
For mLinux models
The default state of the L1 and L2 LEDs is off.
Users control L1 and L2 LEDs as follows:
For L1:
Turn L1 Green mts-io-sysfs store led-cd 1
Turn L1 Red mts-io-sysfs store led-sig1 1
Turn L1 Off mts-io-sysfs store led-cd 0
AND
mts-io-sysfs store led-sig1 0
For L2:
Turn L2 Green mts-io-sysfs store led-sig2 1
Turn L2 Red mts-io-sysfs store led-sig3 1
Turn L2 Off mts-io-sysfs store led-sig2 0
AND
mts-io-sysfs store led-sig3 0
Power Draw
Radio Protocol Cellular
Call Box
Connectio
n No Data
Measured Current at
Maximum Power
1
TX Pulse
2
(AVG)
Amplitude Current for
GSM850 or Peak
Current for HSDPA
Total Inrush Charge
3
Measured in
MilliCoulombs
Total
Inrush
Charge
Duration
during
Powerup
56.0 Volts
