Base Station IP67 for Europe and Asia MTCDTIP-L4E1 Hardware Guide
LE910 Telit Transmission Output Power
Band Power Class
GSM 850/900 MHz 4 (2W)
DCS 1800, PCS 1900 MHz 1 (1W)
EDGE, 850/900 MHz E2 (0.5W)
EDGE, 1800/1900 MHz Class E2 (0.4W)
WCDMA/FDD 800/850/900, 1900/2100 MHz Class 3 (0.25W)
LTE FDD 700/800/850/900, 1800/1900/2100/2600
MHz
Class 3 (0.2W)
LoRa Transmission Output Power for MTAC-003
MTAC-003E00 (868 MHz)
Max output 24.5 dBm
Power Frequency Bandwidth
24.5 dBm 869.525 MHz* 125 kHz
13.7 dBm 868.95 MHz 250 kHz
*Note: Single-channel/high-power mode
I2C Addresses
Component I2C Address (V2.1 Board) I2C Address (Processor
Board)
Comments
TCA9535 I/O Expander 0100000
LM 75AIM Temp Sensor 1001001
LPS25HB Pressure Sensor 1011100
24C04 EEPROM 101011x LSB is A8 memory address
bit
TMP102A Temp Sensor
(U2)
1001000
TMP102A Temp Sensor
(U94)
1001001 Not populated
TMP102A Temp Sensor
(U95)
1001010 Not populated
TMP102A Temp Sensor
(U96)
1001011 Not populated
GPS Receiver 1000010 (default) Can be changed by
software
