PRODUCT OVERVIEW
MultiConnect
®
rCell 100 Series Router LTE Cat 4 MTR-L4G1 Hardware Guide 11
Category Description
SIM Holder Micro (3FF) SIM
Ethernet (LAN) RJ-45, 10/100 Base T
RS-232 DCE 9-pin, female connector
Power 25 mm miniature locking power jack (screw on)
Power Requirements
1
Voltage 7 to 32 VDC
Physical Description
Dimensions 4.17” x 3.0” x 1.15” (10.6cm x 7.6cm x 2.9cm)
Weight 0.51 lbs (0.231 Kg)
Chassis type Aluminum
Environment
Operating Temperature
2
-40° to +80° C
Storage Temperature
2
-40° to +85° C
Humidity Relative humidity 15% to 93% non-condensing
Certifications, Compliance, Warranty
Regulatory EMC and Radio Compliance, FCC Part 15 Class B, FCC Part 22H, FCC Part 24E, FCC Part
27, ICC, RED (EU), RCM (AU)
Safety UL 60950-1 2nd ED, cUL 60950-1, IEC 62368-1
Network Verizon/AT&T/PTCRB
1
Optional power supply must be a Listed ITE power supply marked LPS or Class 2 rated 1.0 A minimum.
Certification does not apply or extend to voltages outside certified range, and has not been evaluated by UL for
operating voltages beyond tested range.
2
For information regarding extended range, please contact MultiTech.
2
UL tested for use at the recommended ambient temperature (Tmra) of 60° C when using a fused cord and 40° C
when using the optional power supply. Additionally, if the MTR is installed in a plastic case, the Tmra is up to 50° C
or 40° C if used with the optional power supply.
Installation in outdoor locations has not been evaluated by UL. UL Certification does not apply or extend to
outdoor applications.
Note: Radio performance may be affected at the temperature extremes. This is considered normal. There is no
single cause for this function. Rather, it is the result of an interaction of several factors, such as the ambient
temperature, the operating mode, and the transmit power.
