Multitech MTR-L4G1 - Ethernet LED Descriptions

PRODUCT OVERVIEW
8 MultiConnect
®
rCell 100 Series Router LTE Cat 4 MTR-L4G1 Hardware Guide
LED Indicators
SIGNAL Signal strength for cellular (RSSI range: 0 - 31)
ALL OFF — Unit is off, not registered on network, or extremely weak signal (0 <= RSSI <
6).
1 Bar “ON” — Very weak signal (7 <= RSSI <14).
1 Bar and 2 Bar “ON” — Weak signal (15 <= RSSI <23).
1 Bar, 2 Bar, and 3 Bar “ON” — Good signal (24 <= RSSI >= 31).
Ethernet LED Descriptions
Two Ethernet LEDs are physically on the RJ-45 connector(s). The table that follows describes these LEDs.
Ethernet Link Right LED on Ethernet connector. Blinks when there is transmit and receive
activity on the Ethernet link. It shows a steady light when there is a valid
Ethernet connection.
Ethernet Speed Left LED on Ethernet connector. Lit when the Ethernet is linked at 100 Mbps.
If it is not lit, the Ethernet is linked at 10 Mbps.
