rCell 100 Series Router LTE Cat 4 MTR-L4G1 Hardware Guide 13
Power Draw
MTR-L4G1-B10 Power Draw
Radio Protocol Live Connection
Idle (No Data)
(mA)
Average
Measured
Current (mA) at
Maximum Power
1
TX Pulse (AVG)
Amplitude
Current for Peak
Current for
HSDPA/LTE
2
Total Inrush
Charge
Measured in
Millicoulombs
(mC)
3
Total Inrush
Charge
DURATION (mS)
during Powerup
(INRUSH
Duration)
9.0 Volts
GSM850 276 617 1.65A 2.71 38.3
WCDMA
1854Mhz
267 711 816 2.71 38.3
LTE Band 3
1747Mhz
278 785 896 2.71 38.3
12.0 Volts
GSM850 210 443 1.25A 1.87 34.2
WCDMA
1854Mhz
205 518 604 1.87 34.2
LTE Band 3
1747Mhz
207 580 652 1.87 34.2
24.0 Volts
GSM850 108 224 600 .818 34.9
WCDMA
1854Mhz
105 258 324 .818 34.9
LTE Band 3
1747Mhz
106 288 356 .818 34.9
48.0 Volts
GSM850 60 127 300 .375 38.2
WCDMA
1854Mhz
58 147 212 .375 38.2
LTE Band 3
1747Mhz
62 152 232 .375 38.2
1
Maximum Power: The continuous current during maximum data rate with the radio transmitter at maximum
power.
2
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE connection. The
transmission burst duration for GSM850 can vary, depending on what transmission scheme is being deployed
(GPRS Class 8, Class 10, GSM, etc.).
3
Total Inrush Charge: The total inrush charge at power on.
