INSTALLING THE DEVICE
20 MultiConnect
®
rCell 100 Series Router LTE Cat 4 MTR-L4G1 Hardware Guide
7. Attach a power cable to your power supply module.
8. Screw-on the power lead from the power supply module into the power connection on the device.
9. Plug the power supply into your power source.
The POWER LED lights after the device powers up.
When the Status LED begins to blink, the device is ready for use.
10. You can configure your device by using your device’s web management interface. You might need to
change the IP address of your computer to be in the same IP and subnet mask range as the device.
a. Open a web browser. In the browser's address field, type the default address for the device:
http://192.168.2.1. (If the browser displays a message that there is a problem with the website's
security certificate, ignore this and click Continue to the webpage).
b. On first-time power up of the device, its Web UI displays the initial setup in commissioning mode
requiring a username and password for the first administrative user. Enter your desired username
and password. Refer to First-Time Setup for more details.
c. If you are not powering up the device for the first time and simply upgrading the firmware of your
device, your existing logins are still active.
Mounting the Device
1. Locate the groove on the bottom of the modem.
2. Slide the mounting tab through the groove.
3. To secure the tab to the desired surface, place and tighten two screws in the holes on either end of the
mounting tab. The dimensions illustration in this guide shows the mounting tab, as well as the dimensions
for placement of the screws.
Resetting the Device
You need:
A pin, paperclip, or similar thin object that can fit into the reset hole
The following is the default condition for the RESET button on the device. You can program a change to the
behavior of the button if needed.
To reset the device:
1. Find the hole labeled RESET. The reset button is recessed into the case.
2. Use the pin to press and release the RESET button as follows:
Reset options:
To reboot, press RESET for less than 3 seconds.
To reboot and restore user-defined defaults (if previously set), press RESET for 3 to 29
seconds.
To reboot, restore factory settings, and erase user-defined defaults, press RESET for 30
seconds or longer.
The device restarts in commissioning mode. The system automatically removes all user
accounts.
