Multitech MultiConnect Conduit MTCDT - MTCDT-LVW2-246 with Modem and no Accessory Cards; MTCDT-246 A no Modem and no Accessory Cards

POWER DRAW
14 MultiConnect
®
Conduit
TM
Hardware Guide
Radio Protocol Idle Cellular
Connection no
data (Amps)
Average Tx
Current at Max
Power Passing
Data (Amps)
1
Peak Tx Current
(Amps)
2
Total Inrush
Charge (mC)
3
Total Inrush
Charge Duration
(mS)
LTE 0.102 0.249 0.316 3.65 17.9
1
Max Power: The continuous current during maximum data rate with the radio transmitter at maximum power.
2
Peak Tx Current: The average peak current during an EGSM900 transmission burst period or LTE connection. The
transmission burst duration for EGSM900 can vary, depending on what transmission scheme is being deployed
(GPRS Class 8, Class 10, GSM, etc.).
3
Total Inrush Charge: The total inrush charge at power on expressed in Millicoulombs (mC).
Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load.
MTCDT-LVW2-246 with Modem and No Accessory Cards
Radio Protocol Idle Cellular
Connectionno
data (Amps)
Average Tx
Current at Max
Power Passing
Data (Amps)
1
Peak Tx Current
(Amps)
2
Total Inrush
Charge (mC)
3
Total Inrush
Charge Duration
(mS)
9.0 Volts
LTE 0.175 0.482 0.556 4.87 9.7
12.0 Volts
LTE 0.148 0.375 0.499 4.2 8.5
24.0 Volts
LTE 0.100 0.214 0.303 3.65 17.9
1
Max Power: The continuous current during maximum data rate with the radio transmitter at maximum power.
2
Peak Tx Current: The average peak current during LTE connection.
3
Total Inrush Charge: The total inrush charge at power on expressed in Millicoulombs (mC).
Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load.
MTCDT-246A No Modem and No Accessory Cards
Voltage No Connections
(Amps)
1
Ethernet
Connected only
(Amps)
2
Maximum
Current (Amps)
3
Total Inrush
Charge (mC)
4
Total Inrush
Charge Duration
(mS)
9.0 Volts 0.147 0.155 0.222 3.92 9.7
12.0 Volts 0.124 0.128 0.175 3.26 8.54
