POWER DRAW
MultiConnect
®
Conduit
TM
Hardware Guide 19
MTCDT-LEU1-247 with Bluetooth, Wi-Fi, and No Accessory Cards
Power Draw
Radio Protocol Idle Cellular Call
Box Connection
No Data
Average
Measured
Current at Max
Power (Wi-Fi
WAN Active
Internet
Upload/Downloa
d)
1
TX Pulse (AVG)
Amplitude
Current for
GSM850 or Peak
Current for
HSDPA/LTE
2
Total Inrush
Charge
Measured
3
Total Inrush
Charge Duration
During Powerup
(Inrush Duration)
9.0 Volts
EGSM 900 MHz 283 mA 635 mA 1.30 Amps 4.87 mC 9.7 mS
LTE 296 mA 850 mA 952 mA 4.87 mC 9.7 mS
12.0 Volts
EGSM 900 MHz 220 mA 490 mA 928 mA 4.2 mC 8.5 mS
LTE 232 mA 675 mA 748 mA 4.2 mC 8.5 mS
24.0 Volts
EGSM 900 MHz 124 mA 258 mA 385 mA 3.65 mC 17.9 mS
LTE 131 mA 343 mA 420 mA 3.65 mC 17.9 mS
1
Maximum Power: The continuous current during maximum data rate with the radio transmitter at maximum
power.
2
Peak Tx Current: The average peak current during a GSM850 transmission burst period or HSDPA connection. The
transmission duration for GSM850 can vary, depending on what transmission scheme is being deployed (GPRS
Class 8, Class 10, GSM, etc.).
3
Total Inrush Charge: The total inrush charge at power.
Note: Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load.
