Technical Specifications
Your MultiModem II modem meets the following specifications:
Trade Name
MultiModem® II
Model Number
MT5600BA
Server-to-Client Data
Rates
V.92/56K speeds when accessing a V.92 server
(actual speed depends on server capabilities and line conditions)
Client-to-Client Data
Rates
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800, 14400, 12000,
9600, 7200, 4800, 2400, 1200, 0-300 bps
Fax Data Rates
14400, 12000, 9600, 7200, 4800, 2400, 300 bps
Data Format
Synchronous and asynchronous
Commands
AT Commands, V.25bis
Command Buffer
60 characters
Modem Compatibility
V.92, V.90, 56K, V.34 enhanced, V.34, V.32terbo, V.32bis, V.32, V.25bis,
V.22bis, V.22; Bell 212A and 103/113; V.42, V.42bis; V.21 & V.23 in
international versions, V.44
Fax Compatibility
V.17/14.4K, Group 3, Class 1, 1.0, 2
Error Correction
V.42
Data Compression
V.44 (6:1 throughput), V.42bis, MNP Class 5 (2:1 throughput)
Speed Conversion
Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19200,
38400, 57600, 115200, and 230400 bps
Mode of Operation
Fax online modes; full duplex over dial-up and two-wire or four-wire leased
lines; data mode, command mode, online command mode, V.54 test mode
Flow Control
XON/XOFF (software), RTS/CTS (hardware)
Transmission Level
-11 dBm (dial-up—varies depending on country or region for which the
modem is set), -10 dBm (leased-line)
Frequency Stability
±0.01%
Receiver Sensitivity
-43 dBm under worst-case conditions
AGC Dynamic Range
33 dB
Connectors
One DB25F (RS-232C/D) connector; three RJ-11s
Cables
Three modular telephone cords (USA); country- or region-specific cordage for
International models; one 9-pin to 25-pin serial cable for International
models; external power supply
Note: Any cables connected to the computer should be shielded to reduce
interference.
Indicators
32-character backlit LCD for status and configuration information; LEDs for
Transmit Data, Receive Data, Carrier Detect, Off Hook, Terminal Ready, and
Test Mode
Speaker
1-inch speaker for call progress monitoring
Manual Controls
Power switch, speaker volume control, four LCD control buttons
