RPR 550IS Series
TM1188 Issue 1 AL2 (Oct. 98)Page 7 - 2
ANY COMPONENT MARKED THUS i ON CIRCUIT DIAGRAMS MAY ONLY BE
REPLACED BY ANOTHER OF AN IDENTICAL TYPE AND SPECIFICATION. THE
LEAD LENGTH AND LOCATION MUST BE IDENTICAL TO THAT OF THE
ORIGINAL COMPONENT.
CONTENTS: Source Drawing Page
RPR 550IS
PCB can be identified by the marking “3061-1213”
10. RPR 550IS Main Board Circuit Diagram (Radio) 2961-1212 Iss. 4 7-21/22
(sheet 2 of 5)
11. RPR 550IS Main Board Circuit Diagram (Decoder) 2961-1212 Iss. 4 7-23/24
(sheet 1 of 5)
12. RPR 550IS Main Board Component Layout 0261-1214 Iss. 1 7-25/26
- Side 1 (sheet 1 of 3)
Notes and Figure A 0261-1214 Iss. 1 7-28
(sheet 3 of 3)
13. RPR 550IS Wire Links - Side 1 0261-1214 Iss. 1 7-29/30
(sheet 3 of 3)
14. RPR 550IS Wire Links - Side 2 0261-1214 Iss. 1 7-31/32
(sheet 3 of 3)
15. RPR 550IS Main Board Component Layout 0261-1214 Iss. 1 7-33
- Side 2 (sheet 2 of 3)
WARNING
