RPR 550IS Series
TM1188 Issue 1 AL2 (Oct. 98) Page 1 - 9
COMPONENTS OF PAGER
RPR 550IS
SERIES
g oz
Without vibrate, without battery 84 2.9
Without vibrate, with battery 109 3.8
With vibrate, N cell 101 3.5
Table 5: Typical Pager Weights
Operational Environment
14. The operational environment is as follows:
a) Temperature: -10
EC to +55EC
b) Humidity: 90% RH (Non-Condensing)
c) Storage Temperature: -20
EC to +70EC
NOTE: There may be some degradation of display performance below 0
EC.
Dimensions
15. The dimensions are as follows:
a) Width: 56mm (2.2ins)
b) Length: 80mm (3.2ins)
c) Thickness: 18mm (0.7ins)
Weight
16. Refer to Table 5 for the weight of the pager.
