RPR 550IS Series
TM1188 Issue 1Page 2 - 2
THE BATTERY DOOR MUST ALWAYS BE SECURED BEFORE USE IN A HAZARDOUS
AREA.
TABLES Page
1. Status Messages 2-5
2. Beep Alert Patterns and Beep Codes 2-7
FIGURES
1. Controls and Indicators 2-3
2. Switch-on Sequence 2-4
3. Display Representation of Call 2-6
4. Battery Removal and Replacement 2-13
ANNEXE
A ENGINEERING MODE
INTRODUCTION
1. Section 2 describes the operation of the RPR 550IS Series of pagers consisting of RPR
551IS, RPR 552IS and RPR 553IS. The use and location of the different buttons and
the various functions they control are also described.
WARNING
CAUTION
PROTECT THE PAGER FROM LIQUIDS, STRONG MAGNETIC FIELDS AND
EXTREME TEMPERATURES. DO NOT LEAVE THE PAGER EXPOSED TO STRONG
SUNLIGHT. AVOID SUCH AREAS AS CAR INTERIORS AND WINDOW LEDGES.
CONTROLS AND INDICATORS
2. Refer to Figure 1 for identification and location of the controls and indicators associated
with the RPR 550IS Series of pagers.
