01 02 03 04
05 06 07
08
09
10 11
12
13 14 15
16
17 18 19 20 21
BIT No.
DATA
NOTE: Check bits 22-31 and Parity bit 32 are not shown.
011110101000100111000
01 02 03 04
05
06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21
BIT No.
DATA
NOTE: Check bits 22-31 and Parity bit 32 are not shown.
0B3
B2
B1 B0 W 1
ID IC
IB
IA
I9 I8 I7 I6 I5
I4
I3 I2 I1 I0
KEY:
B3-B0
W
Beep Code
ID-I0 Address value
RPR 550IS Series
TM1188 Issue 1 Page 3A - 7
Figure 7: Idleword Structure
Figure 8: Address Codeword
Address Codeword
25. The Address Codeword identifies Beep Code, message wait, and address value. Its
structure is shown in Figure 8.
26. Bit 1 (Message flag) is always set to `0'. Bit 7 is reserved for future development of the
code; it is currently set to `1' and is ignored by Mk7 decoders.
27. If the paging receiver detects a Wait flag (Bit 6) set to `1', it will seize the next
composite message within the current system transmission. When the Wait flag is set
to `0', there is no message.
28. When a message or speech follows the address sequence, all addresswords in the call
have the Wait flag set. Addresswords with the Wait flag cleared constitute separate
discrete calls; they cannot be intermingled within the structure of other calls.
29. Beep Code patterns used in the RPR 550IS Series pagers are made up as shown in
Table 1.
