01 02 03 04
05
06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21
BIT No.
DATA
NOTE: Check bits 22-31 and Parit
y
bit 32 are not shown.
1
T3 T2 T1 T0 A7 A6 A5 A4 A3 A2 A1 A0 a7 a6 a5 a4 a3 a2 a1 a0
KEY:
T3-T0 Messa
g
e T
y
pe
(
0-15
)
A7-A0
a7-a0
1st ASCII+ Character
2nd ASCII+ Character
RPR 550IS Series
Page 3A - 8 TM1188 Issue 1
CODE TYPE B3 B2 B1 B0 PATTERN
MULTITONE
BEEP CODE
NORMAL
0 0 0 1 SINGLE BEEP 2
0 0 1 0 DOUBLE BEEP 3
0 0 1 1 TRIPLE BEEP 1
0 1 0 0 CONTINUOUS BEEP 4
0 1 0 1 SINGLE PIP 6
0 1 1 0 DOUBLE PIP 7
OVERRIDE
1010TRIPLE PIP 5
1 0 1 1 CONTINUOUS PIP 8
Table 1: Beep Code Patterns
Figure 9: ASCII+ Message Codeword
Message Codeword
30. The Message codeword, in ASCII+ format, has a four-bit header which identifies the
message type. ASCII+ codewords are used for Display (Type 0) and Control (Type 1)
messages. They carry two ASCII+ characters each (see Figure 9). Messages with an
uneven number of characters have the <NUL> character appended to the end of the
message.
