1.3.2.Interface(Back View)
Figure 1- 3 Interface display
Power port:connect the power cable with this port.
Serial port:connect the serial cable with this port.
LAN port:connect the Lan cable with this port.
USB port:connect the USB cable with this port.
Cash drawer:connect your cash drawer with this port.
USB Port
Power Port
Serial Port
Cash Drawer
LAN Port
