Hand Extruder MEK-18-S / MAK-18-S
Page 12/20 Issue 03.2011/Rev. 03 MUNSCH Kunststoff-Schweißtechnik GmbH
CAUTION Prior to prolonged interruptions of work
(approx. 15-30min), set back temperature controller
(1) by about 2 positions (risk of overheating of the
melt in the melt chamber). Set temperature controller
to welding temperature again approx. 5 minutes
before resuming work.
Before resuming the welding job, the temperatures
must be reset and checked on the running hand
extruder using an external thermometer.
5.4.5 Shutoff
Observe section “Safety”.
• After completion of the welding job, switch off
the drive unit and deposit the hand extruder as
shown in the illustration (see preceding section).
Do not leave the hand extruder unattended
5.4.5.1 Hand extruder with integrated air suppy,
type MAK
• Turn button (1) anti-clockwise to position “0“ to
deactivate the heating circuit.
• Maintain the air supply of the hand
extruder until the unit has completely cooled
down!
• Pull mains connector.
5.4.5.2 Hand extruder with external air supply,
type MEK
• Turn button (1) anti-clockwise to position “0“ to
deactivate the heating circuit.
• Pull mains connector.
• Maintain the air supply of the hand
extruder until the unit has completely cooled
down!
Never use water or another coolant to
accelerate the cooling process!
5.4.6 Transport/storage
Make sure to observe the instructions under section
“Transport/Storage“.
5.5 Set temperatures on temperature controller
Temperature chart for MEK/MAK
Material Melt temperature Air temperature
PP 200 – 240 °C 250 – 300 °C
PE 200 – 240 °C 250 – 300 °C
PVDF 240 – 260 °C 280 – 350° C
If other temperatures are needed, the corresponding
settings can be made on the temperature controller.
5.5.1 Set temperatures
