Munters WF54 - 1 Unpacking the Equipment; Fan Dimensions

5
© Munters Corporation, March 2017
QM1224r3
Cat. No. Cone Type A B C
Below F.O.
D E F G
Cone Height
H
Cone Width
Wall Openings
(W.O.)
WF54 54GCX 65
1
⁄4” 63
1
⁄4” 12
5
⁄8” 56” 58” 22
5
⁄8” 66” 59” 56
1
⁄2”W. x 62
1
⁄2”H.
Dimensions:
Unpacking the EquipmentChapter 1
A
Wall Opening (W.O.)
C
Wall Opening (W.O.)
A
1.2 Fan Dimentions
E
Wall Opening (W.O)
D
H - Cone Width
B
F
Shutter
C
G - Cone Height
Fan Specifications: 60Hz shown (50Hz available)
Power: 230VAC or 230/460 VAC
Phase: 1 or 3
