CoreMC™ 2 Reference Guide - http://musiccomputing.com/support 9 | P a g e
4.2 Installing and Removing the Memory Modules
CAUTION
Exercise extreme care when installing or removing DIMM modules to prevent any
possible damage.
If you need assistance, and to avoid any warranty issues please contact Music
Computing Support before attempting any system changes.
Installing & Removing DIMMs
1. Insert the desired number of DIMMs into the memory slots, starting with P1-
DIMMA1. (For best performance, please use the memory modules of the same
type and the same speed.)
2. Push the release tabs outwards on both ends of the DIMM slot to unlock it.
3. Align the key of the DIMM module with the receptive point on the memory
slot.
4. Align the notches on both ends of the module against the receptive points on
the ends of the slot.
5. Use two thumbs together to press the notches on both ends of the module
straight down into the slot until the module snaps into place.
