off
Mixing: Oscillators 1 and 2 are mixed together
nothing
sync
Mixing and sync: Oscillators 1 and 2 are mixed
together, with oscillator 2’s waveform phase-synced
to oscillator 1’s
nothing
ring
Ring modulation: Oscillators 1 and 2 are mixed
together, and simultaneously sent to a ring-modulator
balance between the original mixed
signal and the ring-modulated signal
xor
Xor modulation: Oscillators 1 and 2 are mixed
together, and simultaneously sent to a digital
XOR
cross-modulator
balance between the original mixed
signal and the
XOR
signal
fold
Foldback distortion: Oscillators 1 and 2 are mixed
together, and sent to a foldback distortion
Amount of foldback distortion
bits
Bit reduction: Oscillators 1 and 2 are mixed together,
and sent to a bit depth reducer
Amount of quantization noise
Filter (S2)
Freq 96|reso 0 mode lp
env2 24|lfo2 0
freq (frequency)
: Filter cutoff frequency.
reso (resonance)
: Filter resonance.
mode (mode)
: Filter mode (low-pass / band-pass / high-pass). Note that this setting takes effect only
if the
SVF
filter board is installed. With the standard SMR-4 filter board, the filter is always a low-pass
no matter the position of this setting!
env2 (env2->vcf)
: Modulation amount from envelope 2 to
VCF
. If you want to set a negative
modulation amount, you can patch env2 to the
VCF
in the modulations section and ignore this
parameter.
lfo2 (lfo2->vcf)
: Modulation amount from
LFO
2 to
VCF
. Again, if you want to set a negative
modulation amount, you can patch the
LFO
2 to the
VCF
in the modulations section and ignore this
parameter.
Envelopes and LFOs (S3)
Ambika has three
ADSR
envelopes, three
part LFOs
and one
voice LFO
.
A
part LFO
is shared among all voices assigned to a part and is used for creating global sweeps,
