4 Electrical connection
• Fan external connection
The external installation wiring is shown in picture below.
• Inner wiring of the box
The inner wiring of the ceiling fan is shown in the diagram, and the connection
is W, V, U, in no order. If the direction of rotation is wrong, please change 2
of them.
Output line
