8.1 Ensure that the locking lever is in the "HITCHING" position:
pins retracted and the springs compressed.
8.2 Approach the loader in line with the implement, the tool
carrier being slightly dumped.
8.3 Enter the hitch into the implement hooks.
8.4 Crowd the implement back while driving forwards until the
unlocking lever is triggered.
