16. SAFETY DEVICE ON LIFTING/CROWDING
If the loaders lifting operation requires people to be in the close proximity, the hydraulic circuit of the loader must have safety
device fitted to it.
This in accordance with the standard EN 12525/A1, from July 2006.
17. CONTROL
Important: Never leave the tractor with loader in raised position.
All spool valves produce an internal leak required for correct operation.
17.1 On tractor valves
Please report to the tractor’s instruction book.
17.2 On MX valves:
17.2.1 Security:
Involuntary loader manoeuvre can be avoided. The
MX joystick can be locked. See diagram.
17.2.2 Lifting-crowding movements
17.2.3 Other
3
rd
FUNCTION :
Green button + Crowding.
Multifunction monolever
C+ and Cu loaders
Monolever
C1 and C2 loaders
