Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 160*UD
7-12
Table 7-2 Parts Configuration Table of 160*UD models
1 Main Rotor Casing CS00100-160S 160S** 1 (S**)
1 Main Rotor Casing CS00100-160M 160M** 1 (M**)
1 Main Rotor Casing CS00100-160L 160L** 1 (L**)
2 Hexagon Socket Head Cap Screw NB35412-040 M12×40 52
3 Alignment Pin NE2013-040 φ13×40 4
4 Eye Bolt NB600-16 M16 1
5 Suction Cover CS00500-160D 160*** 1
6 Gasket, Suction Cover CS00600-160N 160*** 1
7 Eye Bolt NB600-12 M12 2
8 Spring Pin NE3204-010 φ4×10 2
9 O-ring PA11-042 JISB2401 1A P42 2
10 A Plug NF06-004 R1/8 1
10 B Plug NF06-008 R1/4 1
10 C Plug NF06-008 R1/4 1
11 H Bearing Head CS01100-160DH 160*** 1 (*UD)
11 M Bearing Head CS01100-160DM 160*** 1 (*UD)
11 L Bearing Head CS01100-160DL 160*** 1 (*UD)
12 Gasket, Bearing Head CS01200-160N 160*** 1
13 Eye Bolt NB600-12 M12 1
14 Spring Pin NE3204-010 φ4×10 2
15 Plug NF06-008 R1/4 1
16 Bearing Cover CS01600-160D 160*** 1 (*UD)
17 Gasket, Bearing Cover CS01700-160DN 160*** 1 (*UD)
18 1 Hexagon Socket Head Cap Screw NB35412-040 M12×40 17 (*UD)
18 2 Hexagon Socket Head Cap Screw NB35412-080 M12×80 7 (*UD)
19 Alignment Pin NE2010-040 φ10×40 2
20 Spring Pin
NE3203-010
CS02200-160
φ3×10
160S/L
1
1
22 Balance Piston Cover
23 Gasket, Balance Piston Cover
CS02300-160N
NB35410-025
160L**
M10×25
1
11
24 Hexagon Socket Head Cap Screw
25 Male Rotor
CS02520-160S
160S*
160S*
1 (S**)
26 Female Rotor
25 Male Rotor CS02520-160M 160M* 1 (M**)
26 Female Rotor - 160M* 1 (M**)
25 Male Rotor CS02520-160L 160L* 1 (L**)
26 Female Rotor - 160L* 1 (L**)
27 Main bearing
CSH02700-160 Overseas 2
CS02700-160N Domestic 2
28
Side Bearing
CSH02800-160 Overseas 2
CS02800-160N Domestic 2
29
Stop Ring NG11-102 H102 4
30
Balance Piston CS03000-160 160*** 1
30
Balance Piston for high temperatures CS03000-160H 160*** DH 1
31
Key, Balance Piston CS03100-160 160*** 1
32
Stop Ring NG12-050 S50 1
33
Sleeve, Balance Piston CS03300-160 160*** 1
33
Sleeve, Balance Piston for high
temperatures
CS03300-160H 160*** DH 1
34
Set Screw NA83606-015 M6×15 2
To Next Page
