Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 160*UD
7-13
P/N
Part Name
Code No.
Remarks
Q’ty.
35
O-ring PA12-095 JISB2401 1A G95 1
36
Spacer CS03600-160 160*** 1
37
Stop Ring NG11-102 H102 2
38
Thrust Bearing CS03800-160P 7212B 2
38
Ductile retainer
CSC3800-160 NFA 2
CS03800-160N7 NTN 2
39
Lock Nut NG31-012 AN12 2
40
Lock Washer
NG32-012
AW12
2
41
Spacer, Thrust Bearing Outer Race CS04100-160 160*** 2
42
Spacer, Thrust Bearing Alignment CS04200-160 160*** 2
43
Thrust Bearing Gland CS04300-160 160*** 2
45
Hexagon Head Bolt NB111010-030 M10×30 8
46
Conical Spring Washer ND150-010 160*** 8
46
Lock Washer Set (old , plate type) CS0469-D 160*** 8ps/set -
48
Retainer, Oil Seal CS04800-160 160*** 1
49
O-ring PA12-090 JISB2401 1A G90 1
50
Oil Seal CS05000-160VD
SA155
1
51
H
E
Seal Cover CS051000-160BBS 160***BBS 1
51
Seal Cover
CS05100-160HE
160*** (HE)
1
52
Gasket, Seal Cover
CS05200-160N
160***
1
53
Hexagon Socket Head Cap Screw
NB35408-025
M8×25
8
54
L
Unloader Slide Valve (1) L Port
CS05400-160SDL
160S**
1 (S**)
54
M
Unloader Slide Valve (1) M Port
CS05400-160SDM
160S**
1 (S**)
54
H
Unloader Slide Valve (1) H Port
CS05400-160SDH
160S**
1 (S**)
54
L
Unloader Slide Valve (1) L Port
CS05400-160MDL
160M**
1 (M**)
54
M
Unloader Slide Valve (1) M Port
CS05400-160MDM
160M**
1 (M**)
54
H
Unloader Slide Valve (1) H Port
CS05400-160MDH
160M**
1 (M**)
54
L
Unloader Slide Valve (1) L Port
CS05400-160LDL
160L**
1 (L**)
54
M
Unloader Slide Valve (1) M Port
CS05400-160LDM
160L**
1 (L**)
54
H
Unloader Slide Valve (1) H Port
CS05400-160LDH
160L**
1 (L**)
55
Unloader Slide Valve (2) - 160S** 1 (S**)
55
Unloader Slide Valve (2) - 160M** 1 (M**)
55
Unloader Slide Valve (2) - 160L** 1 (L**)
58
Hexagon Socket Head Cap Screw NB35408-025 M8×25 4
59
O-ring PA11-030 JISB2401 1A P30 2
60
Unloader Cylinder CS06000-160S 160S** 1 (S**)
60
Unloader Cylinder CS06000-160M 160M** 1 (M**)
60
Unloader Cylinder CS06000-160L 160L** 1 (L**)
61
Hexagon Socket Head Cap Screw NB35410-025 M10×25 2
62
Hexagon Socket Head Cap Screw NB35410-065 M10×65 6
63
O-ring PA12-125
JISB2401 1A
G125
1
64
Unloader Piston CS06400-160D 160*** 1
65
O-ring PA11-100 JISB2401 1A P100 1
66
Cap Seal CS06600-160 CAP-3BE100 1
67
Push Rod, Unloader Slide Valve CS0671-DS 160S** 1 (S**)
67
Push Rod, Unloader Slide Valve CS0671-DM 160M** 1 (M**)
67
Push Rod, Unloader Slide Valve CS0671-DL 160L** 1 (L**)
