mycom 200MUD User Manual

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 160*UD
7-14
P/N
Part Name
Code No.
Remarks
Q’ty.
68 Guide Pin NE2503-008 φ3×8 1
69 Lock Nut NG31-005 AN05 2
70 Lock Washer NG32-005 AW05 2
73 O-ring PA11-021 JISB2401 1A P21 1
74 Unloader Cylinder Cover CS07400-160 160*** 1
75 O-ring PA12-110
JISB2401 1A
G110
1
76 Hexagon Socket Head Cap Screw NB35408-025 M8×25 8
77 Indicator Cam CS07700-160S 160S** 1 (S**)
77 Indicator Cam CS07700-160M 160M** 1 (M**)
77 Indicator Cam CS07700-160L 160L** 1 (L**)
78 Ball Bearing CS07800-200 #6000 1
79 Stop Ring NG12-010 S10 1
80 Bearing Gland CS08000-200 200*** 1
81
Hexagon Socket Head Cap Screw
NB35406-015
M6×15
3
82
V-ring
CS08200-200B
20×10×12
1
83 Spring CS08300-200 200*** 1
84 Retainer, Indicator Cam Spring CS08400-200 200*** 1
85 Oil Injection Pipe CS08500-160SD 160S** 1 (S**)
85 Oil Injection Pipe CS08500-160MD 160M** 1 (M**)
85 Oil Injection Pipe CS08500-160LD 160L** 1 (L**)
87 Guide Block CS08700-160 160*** 1
88 Stem, Guide Block 160*** 1
89 O-ring PA11-016 JISB2401 1A P16 2
91 Shaft Key CS09100-160 160*** 1
92 Suction Cover Flange without hole CS71400-P125 MYK125A Male 1
93
Gasket, Suction Flange
CR72000-125N
MYK125A
1
94
Hexagon Head Bolt
NB12020-055
M20×55
8
95
Discharge Cover Flange
CS71400-P100CD
MYK100CD Male
1 (*UD)
96 Gasket, Discharge Flange CR72000-100N MYK100A 1
97 Hexagon Head Bolt NB12022-055 M22×55 4
97 Hexagon Head Bolt NB12022-080 M22×80 4
98 Spring Pin NE3203-014 φ3×14 2
100 Mechanical Seal Assembly (BOS)
CS10000-160BT-F7
0
160V** BOS Type 1
100 Mechanical Seal Assembly (BBSE) CS10002-160EBS BBS-E 1
100 Mechanical Seal Assembly (UV4) CS10009-160-F70 UV4 1
100 Mechanical Seal Assembly (BBS3) CS10001-160BBS BBS3 1
120
Unloader Indicator Assembly (With dial)
CS120-IND062WP-
UP
200, 0-100 % 1
120 Unloader Indicator Assembly (No dial) CS120-INDO62WP 200, 0-50 % 1
125
Micro Switch
CS12501-IND06P 200*** Z15GW 2
129 Potentiometer 200-1k CS12900-IND06P with lead wire 1
129 Conductive Potentiometer 200-1k CS12919-E10 with lead wire 1
137 Indicator Dial CS13700-200 1
164 Pipe Gland, Oil Injection CS16400-160 160*** 1
166 Hexagon Socket Head Cap Screw NB35405-012 M5×12 2
235 Spacer, Discharge Flange FX101-160 1
236 Gasket, Discharge Flange Spacer CS23600-160N 1
