mycom 200MUD User Manual

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 160*UD
7-15
P/N
Part Name
Code No.
Remarks
Q’ty.
237 Torsional Slip Washer CS23700-160 160*** 2
247 Hexagon Socket Head Cap Screw NB35406-060 M6×60 4
248
1
Spring Washer for Hexagon Head Cap
Screw
ND330-06 M6 4
249
2
Alignment Pin NE2006-050 φ6×50 2
250 Thrust Washer CS25000-160 160*** 2
252 Gasket, Flange for Electromizer CR72000-025N MYK25A 1
253 Hexagon Head Bolt NB111012-035 M12×35 4
255 Gasket, Flange for Aquamizer CR72000-020N 1
256 Hexagon Head Bolt NB111012-035 M12×35 2
267
Spring Washer for Hexagon Head Cap
Screw
ND330-08 M8 4
432
A
O-ring PA12-085 JISB2401 1A G85 4
433
B
O-ring PA12-085 JISB2401 1A G85 4
605
A
Plug NF06-015 R1/2 1
607
B
Plug NF06-004 R1/8 1
715
Blind Plate for Aquamizer
CS71500-020
20A
1
 The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
MAYEKAWA when placing an order.
 The Code No. of parts shown in parentheses below is applied to the product until the
end of November, 2014:
(P/N 120 Unloader Indicator Assembly, P/N 125 Micro-Switch, P/N 129 Potentiometer)
 For the Code No. of new type indicator part, refer to the separately dedicated
Instruction manual for it.
