UD-series Screw Compressor 7.2 Parts Configuration Table 200*UD
7-18
68
Guide Pin NE2505-012 φ5X12 1
69
Lock Nut NG31-007 AN07 2
70
Lock Washer NG32-007 AW07 2
73
O-ring PA12-030 JISB2401 1A G30 1
74
Unloader Cylinder Cover CS07400-200 200*** 1
75
O-ring PA12-135 JISB2401 1A G135 1
76
Hexagon Socket Head Cap Screw NB35410-025 M10X25 8
77
Indicator Cam CS07700-200S 200S** 1 (S**)
77
Indicator Cam CS07700-200M 200M** 1 (M**)
77
Indicator Cam CS07700-200L 200L** 1 (L**)
78
Ball Bearing CS07800-200 #6000 1
79
Stop Ring NG12-010 S10 1
80
Bearing Gland CS08000-200 200*** 1
81
Hexagon Socket Head Cap Screw NB35406-015 M6×15 3
82
V-ring, Indicator Cam CS08200-200B VH10 NBR 1
82
V-ring, Indicator Cam CS08200-200V VH10 FPM 1
83
Spring CS08300-200 200*** 1
84
Retainer, Indicator Cam Spring CS08400-200 200*** 1
85
Oil Injection Pipe CS08500-200SD 200S** 1 (S**)
85
Oil Injection Pipe CS08500-200MD 200M** 1 (M**)
85
Oil Injection Pipe CS08500-200LD 200L** 1 (L**)
87
Guide Block CS08700-200 200*** 1
88
Stem, Guide Block
89
O-ring PA11-020 JISB2401 1A P20 2
91
Shaft Key CS09100-200 200*** 1
92
Suction Cover Flange without hole CS71400-P150 MYK150A(6") Male 1
93
Gasket, Suction Flange CR72000-150N MYK150A 1
94
Hexagon Head Bolt NB12022-055 M22X55 8
95
Discharge Cover Flange CS71400-P125CD MYK125CD Male 1 (*UD)
96
Gasket, Discharge Flange CR72000-125N MYK125A 1
97
Hexagon Head Bolt NB12020-055 M20X55 8
97
Hexagon Head Bolt NB12020-070 M20X70 8 (*UD)
98
Spring Pin NE3203-016 φ3×16 2
100
Mechanical Seal Assembly (BOS-E1) CS10000-200BE BOS-E1 1
100
Mechanical Seal Assembly (BBSE) CS10002-200EBS BBS-E 1
100
Mechanical Seal Assembly (UV4) CS10009-200-F70 UV4 1
100
Mechanical Seal Assembly (BBS3) CS10001-200BBS BBS3 1
120
Unloader Indicator Assembly (With
dial)
CS120-IND062WP-UP 200, 0-100 % 1
120
Unloader Indicator Assembly (No dial) CS120-IND062WP 200, 0-50 % 1
125
Micro Switch CS12501-IND06P 200*** Z15GW 2
129
Potentiometer 200-1k CS12900-IND06P with lead wire 1
129
Conductive Potentiometer 200-1k CS12919-E10 with lead wire 1
137
Indicator Dial CS13700-200 1
164
Retainer, Oil Injection Pipe CS16400-200 200*** 1
166
Hexagon Socket Head Cap Screw NB35405-012 M5×12 2
167
Plug NF06-015 R1/2 1
