Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 200*UD
7-19
216
Gasket, Lubrication Oil Supply Flange CR72000-020N MYK20A 1
217
Hexagon Head Bolt NB111012-035 M12X35 4
235
Spacer, Discharge Flange FX101-200
1
236
Gasket, Discharge Flange Spacer CS23600-200N
1
237
Torsional Slip Washer CS23700-200 200*** 2
246
Guide, Unloader Slide Valve CS24600-200 200*** 1
247
Hexagon Socket Head Cap Screw NB35408-070 M8X70 3
248
Spring Washer for Hexagon Head Cap
Screw
ND330-08 M8 3
249
Alignment Pin NE2008-060 φ8X60 2
250
Thrust Washer CS25000-200 200*** 2
252
Gasket, Flange for Electromizer CR72000-032N MYK32A 1
253
Hexagon Head Bolt NB111012-040 M12X40 4
255
Gasket, Flange for Aquamizer CR72000-025N MYK25A 1
256
Hexagon Head Bolt NB111012-035 M12X35 4
267
Spring Washer for Hexagon Head Cap
Screw
ND330-10 M10 4
432
O-ring PA62-022 JIS W1516 1A G22 4
528
Sleeve, Oil Seal CS52809-200VD 200V** 1
529
Set Screw NA83606-008 M6X8 2
605
Plug NF06-020 R3/4 1
607
Plug NF06-004 R1/8 1
715
Blind Plate for Lubrication Oil Supply CS71500-020 20A 1
715
Blind Plate for Electromizer CS71500-032 32A 1
744
O-ring PA12-060 JISB2401 1A G60 1
The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
MAYEKAWA when placing an order.
The Code No. of parts shown in parentheses below is applied to the product until the
end of November, 2014:
(P/N 120 Unloader Indicator Assembly, P/N 125 Micro-Switch, P/N 129 Potentiometer)
For the Code No. of new type indicator part, refer to the separately dedicated
Instruction manual for it.
The sizes of O-ring No.432-2 and No.432-2 have been changed to G130 from G135 in October 2012
as a design change.
