UD-series Screw Compressor 7.2 Parts Configuration Table 250*UD
7-20
Table 7-4 Parts Configuration Table of 250*UD models
P/N
Part Name
Code No.
Remarks
Q’ty.
1 Main Rotor Casing CS00100-250S 250S** 1 (S**)
1 Main Rotor Casing CS00100-250M 250M** 1 (M**)
1 Main Rotor Casing CS00100-250L 250L** 1 (L**)
2 Hexagon Socket Head Cap Screw NB35420-060 M20X60 44
3 Alignment Pin NE2016-070 φ16X70 4
4 Eye Bolt NB600-24 M24 1
5 Suction Cover CS00500-250D 250*** 1
6 Gasket, Suction Cover CS00600-250N 250*** 1
7 Eye Bolt NB600-12 M12 2
8 Spring Pin NE3206-012 φ6×12 2
9 O-ring PA12-060 JISB2401 1A G60 2
10
A
Plug
NF06-010
R3/8
1
10
B
Plug
NF06-008
R1/4
1
10
C
Plug
NF06-020
R3/4
1
10
D
Plug
NF06-015
R1/2
1
11 H Bearing Head CS01100-250DH 250*** 1 (*UD)
11 M Bearing Head CS01100-250DM 250*** 1 (*UD)
11 L Bearing Head CS01100-250DL 250*** 1 (*UD)
12 Gasket, Bearing Head CS01200-250N 250*** 1
13 Eye Bolt NB600-12 M12 1
14 Spring Pin NE3206-012 φ6x12 2
16 Bearing Cover CS01600-250D 250*** 1 (*UD)
17 Gasket, Bearing Cover CS01700-250DN 250*** 1 (*UD)
18 1 Hexagon Socket Head Cap Screw
NB35416-050
NB35416-090
M16X50
M16X90
20(*UD)
8 (*UD)
18 2 Hexagon Socket Head Cap Screw
19 Alignment Pin NE2010-050 φ10x50 2
20
Spring Pin
NE3203-010
φ3×10
1
21 Plug NF06-010 R3/8 1
22 Balance Piston Cover
CS02200-250
250V**
1
23 Gasket, Balance Piston Cover CS02300-250N 250*** 1
24 Hexagon Socket Head Cap Screw NB35412-030 M12X30 11
25 Male Rotor CS02520-250S 250S 1 (S**)
26 Female Rotor 250S 1 (S**)
25 Male Rotor CS02520-250M 250M 1 (M**)
26 Female Rotor - 250M 1 (M**)
25 Male Rotor CS02520-250L 250L 1 (L**)
26 Female Rotor - 250L 1 (L**)
27 Main Bearing (O-ring type)
CSH02700-250 Overseas 2
CS02700-250N Domestic
28 Side Bearing (O-ring type)
CSH02800-250 Overseas 2
CS02800-250N Domestic
29 Stop Ring NG11-160 H160 4
30 Balance Piston CS03000-250 250*** 1
31 Key, Balance Piston CS03100-250 250*** 1
32 Stop Ring NG12-080 S80 1
33 Sleeve, Balance Piston CS03300-250 250*** 1
