Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 250*UD
7-21
P/N
Part Name
Code No.
Remarks
Q’ty.
34 Set Screw NA83608-020 M8X20 2
35 O-ring PA11-150 JISB2401 1A P150 1
36 Spacer CS03600-250 250*** 1
37 Stop Ring NG11-160 H160 2
38
Thrust Bearing
CS03800-250P
7317PPS
2
38 Ductile retainer CS03800-250 NSK
39
Lock Nut
NG31-017
AN17
2
40 Lock Washer NG32-017 AW17 2
42 Spacer, Thrust Bearing Alignment1 CS04200-250 250*** 2
43 Thrust Bearing Gland CS04300-250S 250*** 2
45 Hexagon Head Bolt NB111016-045 M16X45 8
46 Conical Spring Washer ND150-016 M16 8
46 Lock Washer Set (old , plate type) CS0469-F 250*** 8ps/set -
48 Retainer, Oil Seal CS04800-250VD
250V** BBS
Ⅲ
BBSE BOS
1
48 Retainer, Oil Seal CS04800-250
250*** UV-4 BBS
Ⅰ
He
-
49 O-ring PA12-135 JISB2401 1A G135 1
50 Oil Seal CS05010-250VD SA1J 75X100X13 1
51
H
E
Seal Cover CS051000-250BBS 250*** 1
51 Seal Cover CS5100-250UV4 250***(UV4)
51 Seal Cover CS05100-250HE 250*** (HE) 1
52 Gasket, Seal Cover CS05200-250N 250*** 1
53 L Hexagon Socket Head Cap Screw NB35412-030 M12X30 8
54 M Unloader Slide Valve (L Port) CS05400-250SDL 250S** 1 (S**)
54 H Unloader Slide Valve (M Port) CS05400-250SDM 250S** 1 (S**)
54 L Unloader Slide Valve (H Port) CS05400-250SDH 250S** 1 (S**)
54 M Unloader Slide Valve (L Port) CS05400-250MDL 250M** 1 (M**)
54 H Unloader Slide Valve (M Port) CS05400-250MDM 250M** 1 (M**)
54 L Unloader Slide Valve (H Port) CS05400-250MDH 250M** 1 (M**)
54 M Unloader Slide Valve (L Port) CS05400-250LDL 250L** 1 (L**)
54 H Unloader Slide Valve (M Port) CS05400-250LDM 250L** 1 (L**)
54 H Unloader Slide Valve (H Port) CS05400-250LDH 250L** 1 (L**)
55 Unloader Slide Valve - 250S** 1 (S**)
55 Unloader Slide Valve - 250M** 1 (M**)
55 Unloader Slide Valve - 250L** 1 (L**)
58 Hexagon Socket Head Cap Screw NB35412-040 M12X40 4
59 O-ring PA11-046 JISB2401 1A P46 2
60 Unloader Cylinder CS06000-250S 250S** 1 (S**)
60 Unloader Cylinder CS06000-250M 250M** 1 (M**)
60 Unloader Cylinder CS06000-250L 250L** 1 (L**)
61 Hexagon Socket Head Cap Screw NB35416-040 M16X40 2
62 Hexagon Socket Head Cap Screw NB35416-090 M16X90 6
63 O-ring PA12-190 JISB2401 1A G190 1
64 Unloader Piston CS06400-250D 250*** 1
65 O-ring PA11-155 JISB2401 1A P155 1
66 Cap Seal CS06600-250 BE155 1
67 Push Rod, Unloader Slide Valve CS0671-FS 250S** 1 (S**)
67 Push Rod, Unloader Slide Valve CS0671-FM 250M** 1 (M**)
