mycom 200MUD

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 400*UD
7-30
P/N
Part Name
Code No.
Remarks
Q’ty.
29
Stop Ring
NG11-250
H250
4
30
Balance Piston
CS03000-400
400V**
1
31
Key, Balance Piston
CS03100-400
400V**
1
32
Stop Ring
NG12-120
S120
1
33
Sleeve, Balance Piston
CS03300-400
400V**
1
34
Spring Pin
NE3210-025
φ10x25
1
35
O-ring
PA12-240
JISB2401 1A G240
1
36
Spacer
CS03600-400
400V**
1
37
Stop Ring
NG11-250
H250
2
38
Thrust Bearing
CS03800-T400M
400***
M
1
38
Thrust Bearing
CS03800-T400F
400***
F
1
39
Lock Nut
NG311-028
AN28
2
40
Lock Washer
NG32-028X
AW28X
2
42
Spacer, Thrust Bearing Alignment
CS04200-400
400***
2
43
Thrust Bearing Gland
CS04300-400M
400***
1
43
Thrust Bearing Gland
CS04300-400F
400***
1
45
Hexagon Socket Head Cap Screw
NN35420-075
M20X75
12
46
Spring Washer, Hexagon Socket Head
Cap Screw
ND330-20
M20
12
51
Seal Cover
CS05100-400
400***
1
53
Hexagon Socket Head Cap Screw
NB35416-040
M16X40
8
54
Unloader Slide Valve (L Port)
CS05400-400SDL
400S**
1 (SUD)
54
Unloader Slide Valve (M Port)
CS05400-400SDM
400S**
1 (SUD)
54
Unloader Slide Valve (H Port)
CS05400-400SDH
400S**
1 (SUD)
54
Unloader Slide Valve (L Port)
CS05400-400MDL
400M**
1 (MUD)
54
Unloader Slide Valve (M Port)
CS05400-400MDM
400M**
1 (MUD)
54
Unloader Slide Valve (L Port)
CS05400-400LDL
400L**
1 (LUD)
54
Unloader Slide Valve (M Port)
CS05400-400LDM
400L**
1 (LUD)
54
Unloader Slide Valve (H Port)
CS05400-400LDH
400L**
1 (LUD)
54
Unloader Slide Valve (L Port)
CS05400-400LLDL
400LL**
1(LLUD)
54
Unloader Slide Valve (M Port)
CS05400-400LLDM
400LL**
1(LLUD)
54
Unloader Slide Valve (L Port)
-
400XL**
1(XLUD)
54
Unloader Slide Valve (M Port)
-
400XL**
1(XLUD)
58
Hexagon Socket Head Cap Screw
NB35416-055
M16X55
7
60
Unloader Cylinder
CS06000-400SD
400S**
1 (SUD)
60
Unloader Cylinder
CS06000-400MD
400M**
1 (MUD)
60
Unloader Cylinder
CS06000-400LD
400L**
1 (LUD)
60
Unloader Cylinder
CS06000-400LLD
400LL**
1(LLUD)
61
Hexagon Socket Head Cap Screw
NB35424-085
M24X85
2
62
Hexagon Socket Head Cap Screw
NB35424-180
M24X180
9
63
O-ring
PA12-300
JISB2401 1A G300
1
64
Unloader Piston
CS06400-400D
400***
1
65
O-ring
PA11-265
JISB2401 1A P265
1
66
Cap Seal
CS06600-400UD
CAP-3BE265
1
67
Push Rod, Unloader Slide Valve
CS0671-QS
400S***
1 (SUD)
67
Push Rod, Unloader Slide Valve
CS0671-QM
400M***
1 (MUD)
67
Push Rod, Unloader Slide Valve
CS0671-QL
400L***
1 (LUD)
67
Push Rod, Unloader Slide Valve
CS06700-400LLD
400LL**
1(LLUD)
67
Push Rod, Unloader Slide Valve
CS06700-400XLD
400XL**
1(XLUD)
