mycom 200MUD User Manual

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 400*UD
7-31
P/N
Part Name
Code No.
Remarks
Q’ty.
68
Guide Pin
NE2506-016
φ6x16
1
69
Lock Nut
NG31-010
AN10
2
70
Lock Washer
NG32-010
AW10
1
73
O-ring
PA12-045
JISB2401 1A G45
1
74
Unloader Cylinder Cover
CS07400-400
400***
1
75
O-ring
PA12-270
JISB2401 1A G270
1
76
Hexagon Socket Head Cap Screw
NB35424-080
M24X80
11
77
Indicator Cam
CS07700-400SD
400S**
1 (SUD)
77
Indicator Cam
CS07700-400MD
400M**
1 (MUD)
77
Indicator Cam
CS07700-400LD
400L**
1 (LUD)
77
Indicator Cam
CS07700-400LLD
400LL**, 400XL**
1(LLUD)
78
Ball Bearing
CS07800-400
#6302
1
79
Stop Ring
NG12-015
S15
1
80
Bearing Gland
CS08000-400
400V**
1
81
Hexagon Socket Head Cap Screw
NB35406-015
M6×15
3
82
V-ring
CS08200-200B
VH10 NBR
1
82
V-ring
CS08200-200V
VH10 FPM
-
83
Spring
CS08300-200
200L**
1
84
Retainer, Indicator Cam Spring
CS08400-400
400V**
1
91
Shaft Key
CS09100-400
400***
1
93
Gasket, Suction Flange
PL300-400
ANSI#300 16" 400A
1
94 Stud Bolt & Nut
NBU611/4-7UNC
1 1/4" -7UNC X
165mm
20
NCU1511/4-7UNC
1 1/4" -7UNC
20
96
Gasket, Discharge Flange
PL300-300
ANSI#300 12"
1
97 Stud Bolt & Nut
NBU611/8-7UNC
1 1/8" -7UNC X
150mm
16
NCU1511/8-7UNC
1
．
1
／
8-7UC
16
100
Mechanical Seal Assembly
CS10000-400
400*** BOD
1
B
Mechanical Seal Assembly
-
400*** BBDE
1
120
Unloader Indicator Assembly (With dial)
CS120-IND062WP-
UP
200
，
0-100 %
1
120
Unloader Indicator Assembly (No dial)
CS120-IND062WP
125
Micro Switch
CS12501-IND06P
200*** Z15GW
2
129
Potentiometer 200-1k
CS12900-IND06P
with lead wire
1
129
Conductive Potentiometer 200-1k
CS12919-E10
with lead wire
1
137 Indicator dial 200S/L CS13700-200
150
O-ring
PA12-290
JISB2401 1A G290
2
166
Hexagon Socket Head Cap Screw
NB35412-025
M12×25
4
215 1
Flange, Lubrication Oil Supply for Main
Journal
CZA01-300C02B
ANSI#300 2"
1
215 2
Flange, Lubrication Oil Supply for Side
Journal
CZA01-300C02B
ANSI#300 2"
1
215
3
Flange, Lubrication Oil Supply for TPTB
CZA01-300C02B
ANSI#300 2"
1
216 1
Gasket, Lubrication Oil Supply for Main
Journal
PL300-050
ANSI#300 2"
1
216 2
Gasket, Lubrication Oil Supply for Side
Journal
PL300-050
ANSI#300 2"
1
216 3
Gasket, Lubrication Oil Supply for TPTB
PL300-050
ANSI#300 2"
1
217 1 Stud Bolt & Nut
NBU605/8-11UNC
5/8-11UNC X 75 mm
8
NCU1505/8-11UNC
5/8-11UNC
8
