Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 250V**
7-15
Table 7-3 Parts Configuration Table of 250V** models
P/N
Part Name
Code No.
Remarks
Q’ty.
1
Main Rotor Casing
CS00100-250VXS
250VS*
1 (VS*)
1
Main Rotor Casing
CS00100-250VXM
250VM*
1 (VM*)
1
Main Rotor Casing
CS00100-250VXL
250VL*
1 (VL*)
1
Main Rotor Casing
-
250VLL*
1 (VLLD)
2
Hexagon Socket Head Cap Screw
NB35420-060
M20×60
44
3
Alignment Pin
NE2016-070
Φ16×70
4
4
Eye Bolt
NB600-30
M30
1
5
Suction Cover
CS00500-250VX
250V**
1
5
Suction Cover
-
250WV*
1 (VLLD)
6
Gasket, Suction Cover
CS00600-250VN
250***
1
7
Eye Bolt
NB600-12
M12
2
8 Spring Pin NE3206-012 Φ6×12 2
9
O-ring
PA12-065
JIS B 2401 G65
1
10
A
Plug
NF06-010
R3/8
1
10
B
Plug
NF06-008
R1/4
1
10
C
Plug
NF06-020
R3/4
1
10
D
Plug
NF06-015
R1/2
1
11
Bearing Head
CS01100-250VXD
250V**
1 (V*D)
11
Bearing Head
CS01100-250VXG
250V*G
1 (V*G)
12
Gasket, Bearing Head
CS01200-250N
250***
1
13
Eye Bolt
NB600-12
M12
1
14
Spring Pin
NE3206-012
Φ6×12
2
16
Bearing Cover
CS01600-250VXD
250V**
1 (V*D)
16
Bearing Cover
CS01600-250VXG
250V*G
1 (V*G)
17
Gasket, Bearing Cover (D)
CS01700-250VD
250V**
1 (V*D)
17
Gasket, Bearing Cover (G)
CS01700-250VG
250V*G
1 (V*G)
18 1 Hexagon Socket Head Cap Screw NB35416-050 M16×50
18 (V*D)
22 (V*G)
18
2
Hexagon Socket Head Cap Screw
NB35416-090
M16×90
8 (V*D)
18
3
Hexagon Socket Head Cap Screw
NB35416-070
M16×70
5
19
Alignment Pin
NE2010-050
Φ10×50
2
20
Spring Pin
NE3203-010
Φ3×10
1
21
Plug
NF06-004
R1/8
1
22
Balance Piston Cover
CS02200-250VX
250V**
1
23
Gasket, Balance Piston Cover
CS02300-250N
250***
1
24
Hexagon Socket Head Cap Screw
NB35412-030
M12×30
11
25
Male Rotor
CS02500-250VS 250VS* 1 (VS*)
26
Female Rotor
25
Male Rotor
CS02500-250VM 250VM* 1 (VM*)
26
Female Rotor
25
Male Rotor
CS02500-250VL 250VL* 1 (VL*)
26
Female Rotor
25
Male Rotor
- 250VLL* 1 (VLL*)
26
Female Rotor
