mycom 200VLD User Manual

2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 250V**
7-16
P/N
Part Name
Code No.
Remarks
Q’ty.
27
Main Bearing O-ring type
CSH02700-250
250VS*, VM*, VL*
2
27
Main Bearing O-ring type
CSH02700-250
250VLL*
4
28
Side Bearing O-ring type
CSH02800-250
250***
2
29
Snap Ring (Internal)
NG11-160
H160
4
30 Balance Piston CS03000-250H 250**H 1
31
Key, Balance Piston
CS03100-250
250***
1
32
Snap Ring (External)
NG12-080
S80
1
33
Sleeve, Balance Piston
CS03300-250H
250**H
1
34
Set Screw
NA83608-020
M8×20
2
35
O-ring
PA11-150
JIS B 2401 P150
1
36
O-ring Spacer
CS03600-250
250***
1
37
Snap Ring (Internal) 250VS*, VM*, VL*
NG11-160
H160
2
37
Snap Ring (Internal) 250VLL*
NG11-160
H160
1
38
Thrust Bearing
CS03800-250P
250*** PPS
2
39
Lock Nut
NG31-017
AN17
2
40
Lock Washer
NG32-017
AW17
2
42
Spacer, Thrust Bearing Alignment
CS04200-250
250***
2
43
Thrust Bearing Gland
CS04300-250
250***
2
45
Hexagon Head Bolt
NB15516-045
M16×45
8
46
Conical Spring Washer
ND150-016
M16 1L
8
46
Lock Washer Set (old, plate type)
CS0469-F
250*** 8p./set
-
48 Retainer, Oil Seal
CS04800-250VDS
250V**
BBS
Ⅲ
BBSE BOS
1
48 Retainer, Oil Seal
CS04800-250S
250V**
UV-4 BBS
Ⅰ
He
1
49
O-ring
PA12-135
JIS B 2401 G135
1
50
Oil Seal
CS05010-250VD
SA1J 75×100×13
1
51 Seal Cover CS05100-250BBS
250V**
BBS
Ⅲ
BBSE BOS
1
52
Gasket, Seal Cover
CS05200-250N
250***
1
53
Hexagon Socket Head Cap Screw
NB35412-030
M12×30
8
54
Unloader Slide Valve
CS05400-250VSD
250VS*
1 (VS*)
54
Unloader Slide Valve
CS05400-250VMD
250VM*
1 (VM*)
54
Unloader Slide Valve
CS05400-250VLD
250VL*
1 (VL*)
54
Unloader Slide Valve
-
250VLL*
1 (VLLD)
58
Hexagon Socket Head Cap Screw
NB35410-055
M10×55
5
60
Unloader Cylinder
CS06000-250VX
250V**
1
61
Hexagon Socket Head Cap Screw
NB35416-040
M16×40
2
62
Hexagon Socket Head Cap Screw
NB35416-090
M16×90
6
63
O-ring
PA12-190
JIS B 2401 G190
1
64
Unloader Piston
CS06400-250S
250***
1
65
O-ring
PA11-155
JISB2401 1A P155
1
66
Teflon Cap Seal
CS06600-250-1
SUNR-BE-155
1
67 Push Rod, Unloader Slide Valve CS0671-FV 250V** 1
67
Push Rod, Unloader Slide Valve
CS06700-250VLLD
250VLL*
1 (VLLD)
68 Guide Pin NE2505-012 Φ5×12 1
