mycom 200VLD User Manual

2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 250V**
7-17
P/N
Part Name
Code No.
Remarks
Q’ty.
69
Lock Nut
NG31-008
AN08
1
70
Lock Washer
NG32-008
AW08
1
73
O-ring
PA12-035
JIS B 2401 G35
1
74
Unloader Cover
CS07400-250
250***
1
74 Unloader Cover CS07460-250
250***
Explosion proof
1
75
O-ring
PA12-170
JIS B 2401 G170
1
76
Hexagon Socket Head Cap Screw
NB35412-030
M12×30
8
77
Indicator Cam
CS07700-250VXS
250VS*
1 (VS*)
77 Indicator Cam CS07700-250VXML 250VL*/VM*
1 (VM*)
1 (VL*)
1(VLLD)
78
Ball Bearing
CS07800-200
#6000
1
79 Snap Ring (External) NG12-010 S10 1
80
Bearing Gland
CS08000-200
200V**
1
81
Hexagon Socket Head Cap Screw
NB35406-015
M6×15
3
82
V-ring
CS08200-200B
20×10×12
1
83
Spring
CS08300-200
200V**
1
84
Retainer, Indicator Cam Spring
CS08400-200
200***
1
91
Shaft Key
CS09100-250
250***
1
92
Suction Flange
with hole
CS71400-P250MK
MYK250A Male
1
93
Gasket, Suction Flange
CS09300-250N
MYK250A
1
94
Hexagon Head Bolt
NB12024-065
M24×65
12
95
Discharge Flange without hole
CS71400-150CDMK
MYK150CD
Male
1 (*UD)
95
Discharge Flange with hole
CR74100-150
MYK150A
Female
1 (*UD)
95
Discharge Flange without hole
-
MYK150A
Male
1 (*UD)
95
Discharge Flange with hole
CR74000-150
MYK150A
Male
1 (*G)
95
Discharge Flange without hole
CR71400-P150
MYK150A Female
1 (*G)
96
Gasket, Discharge Flange (for the case V*G
model or V*D model used No.235)
CR72000-150N MYK150A 1
97
Hexagon Head Bolt (for the case that is not
using No.235 Discharge flange spacer)
NB12022-055 M22×55 8
97
Hexagon Head Bolt (for the case using
No.235 Discharge flange spacer)
NB12022-085 M22×85 8
100 Mechanical Seal Assembly CS10000-250BE BOS-E1 1
100
Mechanical Seal Assembly
CS10002-250EBS
BBS-E
1
100
Mechanical Seal Assembly
CS10001-250BBS
BBS3
1
100
Mechanical Seal Assembly
CS10009-250-F70
UV-4
1
120 Unloader Indicator Assembly
CS120-IND063WP-
VP
V-series 0-100% 1
125
Micro-Switch
CS12501-IND06P
200*** Z15GW
2
127 Micro-Switch Cam CS1279-200V 200VS\L 1
129
Wire wound type Potentiometer
CS12900-INDO6P
with lead wire
1
129
Conductive Plastic type Potentiometer
CS12900-INDO6P
with lead wire
-
137
Indicator Dial
CS13700-200VD
200V** L,M,H-port
1
137
Indicator Dial
CS13700-200VD
250VLL*
1 (VLLD)
215
Flange, Lubricating Oil inlet (Journal)
with hole
CR74000-025 MYK25A Male 1
