mycom 200VLD User Manual

2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 250V**
7-19
P/N
Part Name
Code No.
Remarks
Q’ty.
458
3
Plug
NFO6-008
R1/4
1
459
Plug
NFO6-015
R1/2
1
522
Domed Cap Nut
NC921-36
M36
1
523
O-ring
PA11-040
JIS B 2401 P40
1
528 Oil Seal Sleeve CS52810-250VD 250V** 1
528
Oil Seal Sleeve with O-ring
CS52809-250VD
250V**
1
529
Set screw
NA83606-008
M6×8
2
533
Spring Washer, Hexagon Socket Head Cap
Screw
ND330-06 M6 1
605
Plug
NF06-025
R 1"
1
607
A
Plug
NF06-008
R1/4
1
607
B
Plug
NF06-008
R1/4
1
680
A
Conical Spring Washer, Vi Adjusting Rod
ND160-036
M36
1
680
B
Conical Spring Washer, Vi Adjusting Rod
ND160-036
M36
1
701
Backup Ring
PBP11-067
1
715 Cover Plate, Lubricating oil inlet Flange CS71500-025 25A 1
715
Cover Plate, Liquid injection Flange
CS71500-032
32A
1
744
O-ring
PA12-070
JIS B 2401 G70
1
 The part code of the O-ring is the one assigned to NBR which is standard material.
When the material of the O-ring is other than NBR, a different part code is used for
each material.
If you are using O-rings made from other than the standard material, please contact
MAYEKAWA when placing an order.
 The Code No. of parts shown in parentheses below is applied to the product until the
end of November, 2014:
(P/N 120 Unloader Indicator Assembly, P/N 125 Micro-Switch, P/N 129 Potentiometer)
 For the Code No. of new type indicator part, refer to the separately dedicated
Instruction manual for it.
The sizes of O-ring No.432-2 and No.432-2 have been changed to G130 from G135 in October 2012
as a design change.
.
