mycom 200VLD User Manual

2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 320V*D
7-20
Table 7-4 Parts Configuration Table of 320V*D models
P/N
Part Name
Code No.
Remarks
Q’ty.
1
Main Rotor Casing
CS00100-320VXS 320VS* 1(VSD)
1
Main Rotor Casing
CS00100-320VXM
320VM*
1(VMD)
1
Main Rotor Casing
CS00100-320VXL 320VL* 1(VLD)
2
Hexagon Socket Head Cap Screw
NB35424-080
M24×80
52
3
Alignment Pin
NE2025-080 Φ25×80 4
4
Eye Bolt
NB600-30
M30
2
5
Suction Cover
CS00500-320VXD 320V*D 1
6
Gasket, Suction Cover
CS00600-320VD
320***
1
7
Eye Bolt
NB600-16 M16 2
8
Spring Pin
NE3206-018
Φ6×18
2
9
O-ring
PA11-058 JIS B 2401 P58 1
10
A
Plug
NF06-020
R3/4
1
10
B
Plug
NF06-015 R1/2 2
11
Bearing Head
CS01100-320VXD
320V*D
1
12
Gasket, Bearing Head
CS01200-320N 320*** 1
13 Eye Bolt
NB600-16
M30
(from 2006.03.30)
1
14
Spring Pin
NE3206-018 Φ6×18 2
15
Plug
NF06-010
R 3/8
1
16
Bearing Cover
CS01600-320VXD 320V*D 1
17
Gasket, Bearing Cove
CS01700-320VD
320V*D
1
18
1
Hexagon Socket Head Cap Screw
NB35420-070 M20×70 19
18
2
Hexagon Socket Head Cap Screw
NB35420-120
M20×120
12
18
3
Hexagon Socket Head Cap Screw
NB35420-120 M20×120 6
19
Alignment Pin
NE2016-070
Φ16×70
2
20
Spring Pin
NE3203-016 Φ3×16 1
21
Plug
NF06-008
R1/4
1
22
Balance Piston Cover
CS02200-320 320*** 1
23
Gasket, Balance Piston Cover
CS02300-320N
320***
1
24
Hexagon Socket Head Cap Screw
NB35416-045 M16×45 11
25
Male Rotor
CS02500-320VS 320VS*
1(VSD)
25
Female Rotor
25
Male Rotor
CS02500-320VM 320VM*
1(VMD)
26
Female Rotor
25
Male Rotor
CS02500-320VL 320VL*
1(VLD)
26
Female Rotor
27
Main Bearing O-ring type
CSH02700-320
320***
2
28
Side Bearing O-ring type
CSH02800-320 320*** 2
29
Snap Ring (Internal)
NG11-200
H200
4
30
Balance Piston
CS03000-320H 320**H 1
31
Key, Balance Piston
CS03100-320
320***
1
32
Snap Ring (External)
NG12-100 S100 1
