mycom 200VLD User Manual

2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 320V*D
7-21
P/N
Part Name
Code No.
Remarks
Q’ty.
33
Sleeve, Balance Piston
CS03300-320H 320**H 1
34
Spring Pin
NE3206-014
Φ6×14
1
35
O-ring
PA12-190 JIS B 2401 G190 1
36
O-ring Spacer
CS03600-320
320***
1
37
Snap Ring (Internal)
NG11-200 H200 2
38
Thrust Bearing
CS03800-320
320***
2
39
Lock Nut
NG311-021 AN21 2
40
Lock Washer
NG32-021
AW21
2
42
Spacer, Thrust Bearing Alignment
CS04200-320 320*** 2
43
Thrust Bearing Gland
CS04300-320
320***
2
45
Hexagon Head Bolt
NB15520-055 M20×55 8
46
Conical Spring Washer
ND150-020
M20 1L
8
46
Lock Washer Set (old, plate type)
CS0469-G 320*** 8p./set -
48
Retainer, Oil Seal
CS04800-320VDS
320***
1
48
Retainer, Oil Seal
CS04800-320P
320*** with Seal pot
1
49
O-ring
PA12-160
JIS B 2401 G160
1
50
Oil Seal
CS05010-320VD SA1J 95×120×13 1
51 Seal Cover CS051000-320BBS
320*** BBSⅢ
,
BOS
1
51
Seal Cover
CS05100-320UV4
320*** UV-4
1
52
Gasket, Seal Cover
CS05200-320N
320***
1
53
Hexagon Socket Head Cap Screw
NB35416-040 M16×40 8
54
Unloader Slide Valve
CS05400-320VSD
320VS*
1(VSD)
54
Unloader Slide Valve
CS05400-320VMD 320VM* 1(VMD)
54
Unloader Slide Valve
CS05400-320VLD
320VL*
1(VLD)
58
Hexagon Socket Head Cap Screw
NB35412-055 M12×55 5
60
Unloader Cylinder
CS06000-320V
320V*D
1
61
Hexagon Socket Head Cap Screw
NB35420-050 M20×50 2
62
Hexagon Socket Head Cap Screw
NB35420-110
M20×110
6
63
O-ring
PA12-240 JIS B 2401 G240 1
64
Unloader Piston
CS06400-320S
320***
1
65
O-ring
PA11-200 JIS B 2401 P200 1
66
Teflon Cap Seal
CS06600-320-1
CAP-3BE200
1
67
Push Rod, Unloader Slide Valve
CS0671-GV 320V*D 1
68
Guide Pin
NE2506-016
Φ6×16
1
69
Lock Nut
NG31-010 AN10 1
70
Lock Washer
NG32-010
AW10
1
73
O-ring
PA11-044 JIS B 2401 P44 1
74
Unloader Cover
CS07400-320
320***
1
75
O-ring
PA12-210 JIS B 2401 G210 1
76
Hexagon Socket Head Cap Screw
NB35416-040
M16×40
8
77
Indicator Cam
CS07700-320VS 320VS* 1(VSD)
77 Indicator Cam
CS07700-320VM
320VM* 320VL*
1(VMD)
1(VLD)
