mycom 200VLD User Manual

2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 320V*D
7-22
P/N
Part Name
Code No.
Remarks
Q’ty.
78
Ball Bearing
CS07800-200 #6000 1
79
Snap Ring (External)
NG12-010
S10
1
80
Bearing Gland
CS08000-200 200V** 1
81
Hexagon Socket Head Cap Screw
NB35406-015
M6×15
3
82 V-ring
CS08200-200B
20×10×12 VH10
NBR
1
83
Spring
CS08300-200
200V**
1
84
Retainer, Indicator Cam Spring
CS08400-200 200*** 1
91
Shaft Key
CS09100-320
320***
1
92
Suction Flange
CS71400-P350 MYK350A 1
93
Gasket, Suction Flange
CS09300-320N
MYK350A
1
94
Hexagon Head Bolt
NB12024-075 M24×75 16
95
Discharge Flange
CS71400-P200MK
MYK200A
1
95
Discharge Flange
CS71400-200CDMK MYK200CD 1
96
Gasket, Discharge Flange (for the case V*G
model or V*D model used No.235)
CR72000-200N MYK200A 1
97
Hexagon Head Bolt (for the case that is not
using No.235 Discharge flange spacer)
NB12020-055 M20×55 12
97
Hexagon Head Bolt (for the case using
No.235 Discharge flange spacer)
NB12020-085 M20×85 12
100
Mechanical Seal Assembly
CS10000-320BE
BOS-E1
-
100
Mechanical Seal Assembly
CS10002-320EBS
BBS-E
1
100
Mechanical Seal Assembly
CS10001-320BBS
BBS3
-
100
Mechanical Seal Assembly
CS10009-320-F70
UV-4
1
120 Unloader Indicator Assembly
CS120-IND063WP-
VP
200V** 0-100% 1
125
Micro-Switch
CS12501-INDO6P
200*** Z15GW
2
127
Micro-Switch Cam
CS1279-200V
200VS\L
1
129
Wire wound type Potentiometer
CS12900-IND06P
with Wires
1
129
Conductive Plastic type Potentiometer
CS12900-IND06P with Wires -
137
Indicator Dial
CS13700-200VD
320V*D
1
150
O-ring
PA12-220
JIS B 2401 G220
2
166
Hexagon Socket Head Cap Screw
NB35405-010
M5×10
4
215
Flange, Lubricating Oil inlet (Journal)
without hole
CS71400-040 MYK40A 1
216
Gasket, Lubricating Oil inlet Flange
CR72000-040N
MYK40A
1
217
Hexagon Head Bolt
NB14012-040
M12×40
4
218
Flange, Oil Injection with hole
CR74000-025
MYK25A
1
219
Gasket, Oil Injection Flange
CR72000-025N
MYK25A
1
220
Hexagon Head Bolt
NB14012-035
M12×35
4
235
Spacer, Discharge Flange
(This spacer is not necessary for CD flange.)
- 320*** 1
236
Gasket, Discharge Flange Spacer
CS23600-320N
320***
1
237
Torsional Slip Washer
CS23700-320
125
～
400
2
250
Thrust Washer
CS25000-320
320***
2
251
Electromizer (Economizer) Flange without
hole
CS71400-080 MYK80A Male 1
