mycom 200VLD User Manual

2205Q2JE-HO-S6-N_2020.01.
Chapter 7 Related Documents
SCV-series Screw Compressor 7.2 Parts Configuration Table 320V*D
7-23
P/N
Part Name
Code No.
Remarks
Q’ty.
251
Electromizer (Economizer) Flange with hole
CR74000-080 MYK80A Male 1
252
Gasket. Electromizer (Economizer) Flange
CR72000-080N
MYK80A
1
253
Hexagon Head Bolt
NB15520-055 M20×55 4
254
Liquid Injection Flange without hole
CS71400-050
MYK50A Male
1
254
Liquid Injection Flange with hole
CR74000-050 MYK50A Male -
255
Gasket, Liquid Injection Flange
CR72000-050N
MYK50A
1
256
Hexagon Head Bolt
NB15516-045 M16×45 4
267
Special Spring Washer, Hexagon Socket
Head Cap Screw
ND330-12 M12 5
289
Variable Vi auxiliary Slide Valve
CS28900-320VSD 320VS* 1(VSD)
289
Variable Vi auxiliary Slide Valve
CS28900-320VMD
320VM*
1(VMD)
289
Variable Vi auxiliary Slide Valve
CS28900-320VLD 320VL* 1(VLD)
326
O-ring Gland
CS32600-320
320***
1
420
Spacer, Unloader Positioning
CS42000-320VSD 320VS* 1(VSD)
420
Spacer, Unloader Positioning
CS42000-320VMD
320VM*
1(VMD)
420
Spacer, Unloader Positioning
CS42000-320VLD 320VL* 1(VLD)
421
O-ring
PA11-058
JIS B 2401 P58
2
432
O-ring
PA12-165 JIS B 2401 G165 4
433
O-ring
PA12-165
JIS B 2401 G165
4
444
Vi Adjusting Rod
CS44400-320VSD 320VS* 1(VSD)
444
Vi Adjusting Rod
CS44400-320VMD
320VM*
1(VMD)
444
Vi Adjusting Rod
CS44400-320VLD 320VL* 1(VLD)
446
Vi Square Washer, Teflon Bushing
CS44600-250VD
250V***
1
448
Teflon Bushing
CS44800-320VD 320V*D 1
449
Thrust Washer
CS44900-320VD
200V**
2
450
O-ring
PA11-044 JIS B 2401 P44 2
451
O-ring
PA11-050A
JIS B 2401 P50A
1
452
Hexagon Socket Head Cap Screw
NB35406-020 M6×20 1
453
Hexagon Nut
NC140-36
M36
1
458
1
Plug
NF06-015 R1/2 1
458
2
Plug
NF06-004
R1/8
2
458
3
Plug
NF06-008 R1/4 1
459
Plug
NF06-015
R1/2
1
522
Domed Cap Nut
NC921-36 M36 1
523
O-ring
PA11-050A
JIS B 2401 P50A
1
528
Oil Seal Sleeve
CS52810-320VD 320*** 1
528
Oil Seal Sleeve with O-ring
CS52809-320VD
320***
1
529
Set screw
NA83606-010 M6×8 2
533
Spring Washer, Hexagon Socket Head Cap
Screw
ND330-06 M6 1
599
Guide Pin
NE3206-016
Φ6×16
1
600
Retainer, Vi adjusting Rod
CS60000-320VD
320V*D
1
601
Flange, Lubricating Oil inlet (F Rotor side)
CR74000-020
MYK20A
1
602
Gasket, Lubricating Oil inlet (F Rotor side)
CR72000-020N
MYK20A
1
