2200LZJE-HO-C6-N_2013.12.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 2016**C 7.2 Development Views, Assembly Sectional Views, and Parts Configuration Tables
7-18
No. Part name Code No. Remarks
Q’ty.
LLC LMC LSC MSC SSC
157 Key, Driven Hub CS15700-2016C 1 1 1 1 1
158 Key, Drive Hub CS15800-2016C 1 1 1 1 1
159 Set Screw NA83608-015
M8×15 knurled,
anti-loosening
1 1 1 1 1
160 Lock Nut NG31-010 AN10 1 1 1 1 1
161 Lock Washer NG32-010 AW10 1 1 1 1 1
162
Hexagon Socket Head
Cap Screw
NB35406-045 M8×45 5 5 5 5 5
163 O-ring PA12-025 JISB2401 1A G25 1 1 1 1 1
164
Retainer, Oil Injection
Pipe
CS16400-2016C 1 1 1 1 1
165 O-ring PA12-025 JISB2401 1A G25 1 1 1 1 1
166
Hexagon Socket Head
Cap Screw
NB35408-030 M8×30 4 4 4 4 4
168
Pipe Guide, Oil
Injection
CS16800-2016 1 1 1 1 1
197 O-ring PA11-040 JISB2401 1A P40 1 1 1 1 1
215-1
Flange, Lubrication Oil
Supply (1)
CS71300-025 JIS20K 25A(1") 1 1 1 1 1
215-2
Flange, Lubrication Oil
Supply (2)
CS71300-020 JIS20K 20A(3/4") 1 1 1 1 1
216-1
Gasket, Lubrication Oil
Supply Flange (1)
CS71200-025N JIS20K 25A 1 1 1 1 1
216-2
Gasket, Lubrication Oil
Supply Flange (2)
CS71200-020N JIS20K 20A 1 1 1 1 1
217-1 Hexagon Head Bolt NB111016-045 M16×45 4 4 4 4 4
217-2 Hexagon Head Bolt NB111012-035 M12×35 4 4 4 4 4
218
Flange, Injection Oil
Supply
CS71300-015 JIS20K 15A(1/2") 1 1 1 1 1
219
Gasket, Injection Oil
Supply Flange
CS71200-015N JIS20K 15A 1 1 1 1 1
220 Hexagon Head Bolt NB111012-035 M12×35 4 4 4 4 4
237-1
Torsional Slip Washer
(1)
CS23700-200 200*** 2 2 2 2 2
237-2
Torsional Slip Washer
(2)
CS23700-160 160*** 2 2 2 2 2
245
Special Spring Washer
for Hexagon Socket
Head Cap Screw
ND330-08 M8 5 5 5 5 5
250-1 Thrust Washer (1) CS25000-200 200*** 2 2 2 2 2
250-2 Thrust Washer (2) CS25000-160 160*** 2 2 2 2 2
267-1
Special Spring Washer
for Hexagon Socket
Head Cap Screw
ND330-10 M10 4 4 4 4 4
267-2
Special Spring Washer
for Hexagon Socket
Head Cap Screw
ND330-08 M8 4 4 4 4 4
420 Unload Spacer CS42000-2016
For 2016*LC(2)
20% load
1 - - - -
420 Unload Spacer
For 2016*MC(2)
20% load
- 1 - - -
420 Unload Spacer
For 2016*SC(2)
20% load
- - 1 1 1
421 O-ring PA12-030 JISB2401 1A G30 - - 1 1 1
421 O-ring PA11-030 JISB2401 1A P30 2 2 - - -
423 Unload spacer
Used for MSC
low-stage only.
- - - 1 -
To Next Page
