hyperion - OPERATING INSTRUCTION
● The criteria adopted to dene hyperion immune to EMC disturbances are:
- Communication between hyperion and the computer is never interrupted;
- The data exchanged between hyperion and the computer are never corrupted (image integrity);
- hyperion does not emit uncontrolled x-rays;
- hyperion x-ray emission values (kV, mA and exposure time) fall within the tolerances given in paragraph “tech-
nical data – radiological data” in this manual.
Manufacturer’s declaration and recommendations – Electromagnetic emissions
hyperion is suited for use in the electromagnetic environment specied below.
The customer or user of hyperion must assure that it is used in said environment.
Emission testing Conformity Electromagnetic environment – rec-
ommendations
RF emissions
CISPR 11
Group 1 hyperion uses RF energy only for in-
ternal functions. Therefore its RF emis-
sions are very low and do not cause in-
terferences to other nearby equipment.
RF emissions
CISPR 11
Class A hyperion can be used in residential in-
stallations (or connected to the public
low voltage power supply system for
household use) taking the following
precautions: hyperion may be used
only by properly trained dental profes-
sionals or paramedics. hyperion may
cause radio interferences and disturb
nearby equipment. Counter-measures
may be required such as re-directing
or moving hyperion or shielding the in-
stallation room.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage uctuation and icker emis-
sions Compliant
IEC 61000-3-3
Complied
Manufacturer’s declaration and recommendations – Electromagnetic immunity
hyperion is suited for use in the electromagnetic environment specied below.
The customer or user of hyperion must assure that it is used in said environment.
Immunity testing Testing level IEC60601 Conformity level Electromagnetic environ-
ment – recommendations
Electrostatic Discharge
(ESD) contact contact
IEC61000-4-2
±6 kV contact
±8 kV airborne
±6 kV contact
(metal casings)
±8 kV airborne
(display, x-ray button)
Wooden, concrete or ceramic
tile oors may be used. If the
oor is covered in synthetic
material, the relative humidity
must be more than 30%.
Fast electric transistors
on power supply lines
on power supply lines
IEC61000-4-4
±2 kV on power supply lines
±1 kV on signal lines (in/
out) on signal lines (LAN)
±2 kV on power supply lines
±1 kV on signal lines (LAN)
The quality of the supply volt-
age may be the same as that
typically found in hospitals or
business environments.
Surge
IEC61000-4-5
±1 kV differential mode
±2 kV common mode
±1 kV differential mode
±2 kV common mode
The quality of the supply volt-
age may be the same as that
typically found in hospitals or
business environments.
Voltage uctuations,
dips and brown outs
in power supply line
IEC61000-4-11
<5 % UT per 0.5 cycles
40 % UT per 5 cycles
70 % UT per 25 cycles
<5 % UT per 5 s
<5 % UT per 0.5 cycles
40 % UT per 5 cycles
70 % UT per 25 cycles
<5 % UT per 5 s
The quality of the supply volt-
age may be the same as that
typically found in hospitals or
business environments.
